Connection, installation / mounting
Product manual 2CKA001473B9482
23
6.2 Mounting
Caution! The device can sustain damage when coming into contact with
hard objects!
The plastic parts of the device are sensitive.
– Pull the attachment off only with your hands.
– Do not lever parts off with screwdrivers or similar hard objects.
In Germany the flush-mounted insert must only be installed in flush-mounted boxes according to
DIN 49073-1, Part 1, or suitable surface-mounted housings.
Different installation standards apply in other countries. These are to be taken into account
when used in connection with a different support ring and flush-mounted box.
To install the device, perform the following steps:
1
Option
1. Installing the removal protection.
– Push the removal protection into
position by hand.
(The removal protection is not a
component part of the device and
is to be ordered separately.)
Fig. 13: Installation of the removal protection
2. Installing the support ring.
Fig. 14: Installation of the support ring
