Connection, installation / mounting
Product manual 2CKA001473B9482
21
6.1 Installation site
For proper commissioning please observe the following points:
■
The device should be installed at a
height of approximately 150 cm from
the floor and 50 cm from a door
frame.
Fig. 6: Installation site - Distance
■
The device should be installed on a
wall opposite a radiator.
Fig. 7: Installation site – Position of radiator
■
The angles of the room architecture
should not separate a radiator and
the device from each other.
Fig. 8: Installation site - Room architecture
■
Installing a device close to a radiator
or behind curtains is not practical.
Fig. 9: Installation site – Position of RTC
50 cm
150 cm
