Description of application and parameters
Application "General functions"
Product manual 2CKA001473B9482
158
11.6.5.8 Save input signal
Options: Deactivated
Activated
■
Deactivated:
– Input telegrams are not saved during the blocking phase.
■
Activated:
– Input telegrams are saved during the blocking phase.
The parameter is used to specify whether input signals are saved during the blocking phase.
The further behaviour depends on the setting of the "Data flow direction" parameter.
For example:
Data flow direction: Input towards the output.
If the setting "activated" has been selected, the output sends its value after the blocking phase if
a telegram has been received on the input during the blocking phase.
Note
This parameter can only be set if the "Enable object" parameter is set on
"activated".
