43
Value 1
Setting dependent on object
type
Value 2
Setting dependent on object
type
Function block RTC —
Control settings —
General
Jump-back time to the primary function
5 s / 10 s / 20 s / 30 s / 1
min. / 2 min. / 4 min.
Function block RTC —
Control settings —
Temperature display
Temperature unit °C / °F
Setting the temperature unit via object No / yes
Display of the actual temperature No / yes
Waiting period for display of actual
temperature
5 s / 10 s / 20 s / 30 s / 1
min. / 2 min. / 4 min.
Function block RTC —
Control settings —
Brightness settings
Day/Night mode No / yes
Brightness of display backlighting Dark / bright
Function block RTC —
Control settings — Button
configuration
Button top left Eco / ON/OFF / Menu / Fan
Button top right Eco / ON/OFF / menu / fan
Function block RTC —
RTC — General
Device function
Single device / master
device / slave device
Overwrite local setting at download Deactivated / activated
Control function
Heating / heating with
additional stage / cooling /
cooling with additional stage
/ heating and cooling /
heating and cooling with
additional stages
Operating mode after reset
Comfort / standby / Eco
mode / frost/heat protection
Send cyclic "In operation" (min) 5 - 3000
Additional functions/objects No / yes
Delay time for read telegrams after reset (s) 1 - 255
Function block RTC —
RTC — Heating
controller
Control value type
2-point 1 bit, on/off /
2-point 1 byte, 0/100% /
PI continuous, 0-100% /
PI PWM, on/off / fan coil
Heating type
Area (e.g. floor heating) 4°C
200 min. / convector (e.g.
heater) 1.5°C 100 min. / free
configuration / fan coil 4°C
90 min. / free configuration
Setting dependent on
"Control value type"
P-component (x 0.1°C) 10 - 100
I-component (min) 0 - 255
Advanced settings No / yes
Function block RTC —
RTC — Basic stage
heating
Status object heating No / yes
Mode of control value Normal / inverse
Hysteresis (x 0.1°C) 3 - 255
Control value difference for sending of
heating control value
2% / 5% / 10% / send cyclic
only
