MODULE 5: MISCELLANEOUS
5-16 ARCHITECT
®
RSH Service Training Guide
FOR INTERNAL USE ONLY 201532-102
 Hang Sample Handler on i2000
SR
®
Processing Module
 Install STAT and Sample RSH Aspiration Covers
 Fully seat Sample Handler
 Tighten Mounting Clamps
 Loosen i2000
SR
System Mounting Clamps
NOTE: This will be located after c8000 RSH installation procedure.
 Prepare Connection Pins
 Install Mounting/Alignment pins sets on i2000
SR
System
 Insert top opening Mounting/Alignment pins c8000
®
System
 Insert lower Mounting/Alignment pins c8000
®
System
 Install screws to mount center brace
 Route Bar Code and Keypad (LUI) cables
 Connect i2000
SR
and c8000 System Module Sample Handlers
 Verify seam between Sample Handler Sections
 Tighten Six Set Screws
 Verify Bearing surface
 Verify level Sample Probes
 Adjust i2000
SR
System level
 Secure Sample Handler to i2000
SR
System Processing Module
 Install Center Support Brace on Sample Handler
 Connect Front Center Core Support Bracket
 Connect Rear Structure Interface Bracket to c8000 System
 Connect N540 Keypad/Bar Code Cable
 Route Carrier Transport Belt
 Attach Carrier Transport Belt
 Attach Belt Tension
 Install Carrier Transport
 Install WS72 ci8200
®
System Integrated Flex Cable
 Install Priority Light Sensors and Unit Detect Boards
 Install Light Panel Access Covers
 Install Interlock Sensor Boards
 Install c8000 System Carrier Positioner cables
 Install c8000 System Carrier Positioner Sensor cable will into SIB J7 Module 1
 Install WS82 c8000 and WS83 i2000
SR
System Carrier Positioner Motor cables
 Secure right ground strap to Sample Handler
 Connect RSH Signal Interface Board (SIB) cables
 Connect Sample Handler Motor Drive cables
 Install left and right rear covers
 Install rear center closeout
 Install Processing Module Rear Top Cover
 Install Processing Module Front Top Cover
 Install Top Cover Center Bar
(Continued)
