P7280/P7270I/P7280 Refresh/P7270I Refresh
Condential 4
Item P/N Description Parts Supply
1 70.87Y01G001 SUB ASSY BOTTOM MODULE
2 70.87Y05G001 SUB ASSY ENGINE MODULE
70.87Y31GR01 ASSY ENGINE MODULE
P7270I(SERVICE)
V
3 70.87Y17G001 PCBA ASSY MAIN-IO
70.87Y32GR01 PCBA MAIN BD MODULE FOR
P7270I(SERVICE)
V
70.87Y33GR01 PCBA I/O BD MODULE FOR
P7270I(SERVICE)
V
4 61.87Y03G001 FRONT SHIELDING
5 70.87Y15G001 SUB ASSY BACK SHIELDING MODULE
6 85.WA123G080 SCREW PAN TAP M3*8 Ni
7 85.1A123G060 SCREW PAN MECH M3*6 Ni
8 85.1A123G040 SCREW PAN MECH M3*4 Ni
9 61.87Y14G001 OFFRAY GLASS FIX PLATE SUS301
10 52.87Y10G001 SILICONE RUBBER FOR OFF-RAY
11 61.87Y16G001 HEATSINK OFFRAY AL1070 P7270I
12 70.87Y04G001 SUB ASSY FRONT MODULE
70.87Y34GR01 ASSY FRONT COVER MODULE
P7270I(SERVICE)
V
13 70.87Y24G001 SUB ASSY RIGHT MODULE
14 70.87Y23G001 SUB ASSY LEFT MODULE
15 70.87Y03G001 SUB ASSY BACK MODULE
70.87Y37GR01 ASSY BACK COVER MODULE
P7270I(SERVICE)
V
16 85.1A326G060 SCREW PAN HEAD MECH M2.6*6
17 85.005AGG408 SCREW HEX I/O #4-40 H4*L8
18 51.87Y24G001 LIGHTCUT MYLAR FOR LENS
19 70.87Y02G001 SUB ASSY TOP MODULE
70.87Y38GR01 ASSY TOP COVER MODULE
P7270I(SERVICE)
V
20 61.87Y24G001 SUB ASSY TOP SHIELDING
