Acer P7280 Refresh - Disassemble Lamp Driver Module

P7280/P7270I/P7280 Refresh/P7270I Refresh
Condential 2-30
2-22 Disassemble Lamp
Driver Module
1. Unscrew 4 screws
(as red circle / only for P7270I/P7270I
Refresh)
2. Disassemble P7270I/P7270I
Refresh Lamp Driver Module
3. Unscrew 3 screws
(as yellow circle / only for P7280/P7280
Refresh)
4. Disassemble P7280 /P7280 Refresh
Lamp Driver Module and tear off the
Mylar (as red square)
P7270I/P7270I Refresh
P7280/P7280 Refresh
