Acer P7280 Refresh - Assemble Wireless Module (Only for P7270 I;P7280 Refresh)

P7280/P7270I/P7280 Refresh/P7270I Refresh
Condential 2-58
2-50 Assemble Wireless
Module (only for P7270i/
P7270i Refresh)
1. Insert 1 connector (as yellow square)
2. Screw 3 screws (as green circle)
3. Assemble the Antenna Cable (as green
square) and screw 1 Washer and 1 Nut
(as yellow circle)
