IV
Table of Content
Chapter 1 Introduction
Highlight 1-1
Compatible Mode 1-4
Product Overview 1-9
Chapter 2 Disassembly Process
Equipment Needed & Product Overview 2-1
Disassemble Top Cover Module 2-2
Disassemble Lamp Module 2-4
Disassemble Wireless Module(only for P7270i/P7270I refresh)
2-5
Disassemble Top Shielding Module 2-7
Disassemble Zoom Ring and Focus Ring Module 2-10
Disassemble Back Cover Module 2-11
Disassemble Left and Right Cover Module 2-12
Disassemble Front Cover Module 2-13
Disassemble Front Shielding 2-14
Disassemble Main Board Module and I/O Board Module 2-15
Disassemble Shielding Module 2-17
Disassemble LVPS Module 2-19
Disassemble Fan Module 2-21
Disassemble Engine Module 2-22
Disassemble Color Wheel Module 2-24
Disassemble DMD Board and DMD Ship 2-25
Disassemble Lamp Blower Module 2-26
Disassemble ROD Blower Module 2-27
Disassemble ROD Duct Module 2-28
