Acer P7280 Refresh - Disassemble Back Cover Module

P7280/P7270I/P7280 Refresh/P7270I Refresh
Condential 2-11
2-7 Disassemble Back Cover
Module
1. Unscrew 2 screws (as red circle)
2. Unscrew 8 hex screws (as yellow circle)
3. Unscrew 3 screws (as green circle)
4. Disassemble the Back Cover Module
Note: There are 1 tenon on each side when
you disassemble the Back Cover
Module (as red square)
