P7280/P7270I/P7280 Refresh/P7270I Refresh
Condential 2-14
2-10 Disassemble Front
Shielding
1. Unscrew 7 screws
(as red circle)
2. Disassemble the Front Shielding
A
C
B
A
B
C
