Acer P7280 Refresh - Disassemble Interrupt Switch Module

P7280/P7270I/P7280 Refresh/P7270I Refresh
Condential 2-32
2-24 Disassemble Interrupt
Switch Module
1. Unscrew 1 screw (as red circle) and
disassemble 1 Interrupt Switch Module
on each side
2. Use Tweezers to loose 2 tenons (as yellow
circle) and disassemble the Interrupt
Switch from the Holder
