2-8 Disassemble Left and
Right Cover Module
1. Unscrew 3 screws on Right Cover
(as red circle)
2. Disassemble the Right Cover Module (as
green arrow) and tear off the Mylar
(as red square)
3. Unscrew 1 screw on Left Cover
(as yellow circle)
4. Disassemble the Left Cover Module
(as yellow arrow)
Note: There are 3 tenons on Left Cover
Module and the same of Right Cover
Module (as green square)
