P7280/P7270I/P7280 Refresh/P7270I Refresh
Condential 7
Item P/N Description Parts Supply
1 75.87Y08G001 BUY ASSY BOTTOM COVER
70.87Y35GR01 ASSY BOTTOM COVER MODULE
P7270I(SERVICE)
V
2 61.87Y15G001 DMD GROUND BRKT
3 61.00069G001 HEX SCREW L=16 M3
4 41.82V13G001 EMI TAPE W20*L40
5 41.81M02G001 EMI GASKET W17*H23*L30
6 70.87Y06G001 SUB ASSY FAN105-32 MODULE
70.87Y36GR01 ASSY AXIAL FAN MODULE
P7270I(SERVICE)
V
8 61.87340G001 STANDOFF M3*4L D8.0 2100MP
9 70.87Y08G001 SUB ASSY ROD BLOWER MODULE
49.87Y02G001 SUNON GB1205PKV1-8AY 50X50X20
OPTICAL ENGINE BLOWER
V
10 70.87Y09G001 SUB ASSY ELEVATOR MODULE
11 51.87Y20G001 ROD BLOWER DUCT PPS-AR04B
12 70.87Y21G001 ASSY ELEVATOR FOOT RIGHT
13 70.87Y22G001 ASSY ELEVATOR FOOT LEFT
14 61.83C10G001 ELEVATOR SPRING
15 86.03123G035 HEX CAP HEAD NUT M3*0.5P L3.5
16 70.87Y11G001 SUB ASSY LVPS MODULE
75.85H14G001 ASSY LVPS LITEON HD81 V
75.87Y04G001 BUY ASSY INTERLOCK SWITCH AC-
ROLECTRIC-H8351AB P7270I
V
17 61.89532G001 HEX SPACER H29
18 70.87Y12G001 SUB ASSY LAMP DRIVER 280W
70.87Y39GR01 ASSY LAMP DRIVER MODULE
P7270I(SERVICE)
V
19 85.00923G200 SCREW HEX PLASTIC M3*H20
