Acer P7280 Refresh - Page 156

P7280/P7270I/P7280 Refresh/P7270I Refresh
Condential 27
Item P/N Description Parts Supply
70.87Y31GR01 ASSY ENGINE MODULE P7270I(SERVICE) V
1
11.009F0G012 CNNT F 203PIN FOR 0.7" LVDS XGA
MOLEX LGA 47475-0203
V
2
23.83M06G001 GLASS RELAY WITL EDGE BLACK PAINT-
ING
3 23.87M06G001 GLASS RELAY B270 Φ37mm ISUZU
4 23.88E20G001
A39 Y.O. CONDERSOR L2(Φ=21.2MM;SID
E1=93.8632CX;SIDE2=-24.0905CX)
5 23.88E20G011
A39 Y.O. CONDERSOR L3(Φ=20.2MM;SID
E1=93.8632CX;SIDE2=-24.0905CX)
6 48.83N01G001 DMD 0.7 XGA 12° LVDS TYPE A V
7 51.00210G001 DMD SCREW WASHER A39
8 51.87P04G001 DMD INSULATION MYLAR A39
9 52.80J01G001
DMD ANTIDUST RUBBER 739 SILICONE
RUBBER
10 52.83N15G001
FUJIPOLLY SARCON XR-Hj, THERMAL
PAD FOR DMD HEAT SINK, K=14
V
11 61.00084G001 WAVE SPRING WASHER
12 61.83J16G003
DMD LIGHT MASK FOR GLASS RELAY
PD528
13 61.87P20G001 RELAY BRACKET SUS301 0.3t A39
14 61.87P04G001 DMD PLATE AL A39
15 61.87P08G001 STEP ROD SPRING SUS301 A39
16 61.87P20G001 RELAY BRACKET SUS301 0.3t A39
17 61.88611G001 DMD SCREW Ivy10X V
18 61.89626G001 HEATSINK SCREW EP759
19 61.89630G001 HEATSINK SPRING EP759/PD726
20 70.87P02G001 ASSY ENGINE BOTTOM MODULE A39
21 70.87P03G001 ASSY ENGINE LENS BASE MODULE A39
22 70.87Y20G001
ASSY ENGINE ROD(XGA) BASE MODULE
P7270I
23 70.87P06G001 ASSY ROD(XGA) MODULE A39
