4. Screw 3 screws (as yellow circle) and
paste Mylar (as blue square)
5. Assemble Main Board Module
6. Insert 11 connectors (as yellow square)
and screw 4 screws (as red circle)
Note: Add 1 connector (as orange square/
only for P7280/P7280 Refresh)
Only for P7280/P7280 Refresh (Blower Cable)
A
A
To Next Page
