7
J11,J12 Current Source Output 30 100 750 30 0
J12,J13 Current Sink Output 30 100 750 30 0
J14,J13 Voltage And Frequency Output 30 100 750 30 0
Output parameters, simple connection
Connection Function Uo/V Io/mA Po/mW Co/µF Lo/mH
J1-J4 Resistance Measuring and Analog Output 5 10.1 13 82 300
J5,J6
Thermocouple Measuring and Analog
Output
5 10 13 82 300
J7,J9
HART (External Power supply and External
Resistance)
25.2 79.16 499 0.107 9
J8,J9 Current Measuring 5 0.85 1.1 87 100
J10,J9 Voltage, Frequency AND Switch Measuring 5 0.85 1.1 87 100
J7,J8
Loop Circuit Transmitter Current Measuring
/ HART(Internal Power and Resistance)
25.2 79.16 499 0.107 9
J11,J12 Current Source Output 21 55 289 0.165 30
J12,J13 Current Sink Output 21 55 289 0.165 30
J14,J13 Voltage And Frequency Output 21 55 289 0.165 30
