Adtech ADTECH4 CNC Series User Manual

ADTECH4 SeriesCNC Maintenance Manual
Function
Name
Specification
interpolation
Operating mode
MDI, auto, manual, single step, edit
Yes
Testing function
Test run, single program section, hand wheel
Yes
Coordinate system and
pause
Pause (sec/ms)
G04 X/P_
Coordinate system setting
G92 (M series)
G50 (L series)
Automatic coordinate system setting
Yes
Safe functions
Soft & hard limit check
Yes
Emergency stop
Yes
Program storage
Program storage capacity, storage quantity
Capacity: 60MB
100 work areas
No limit on processing file quantity
Program edit
Program edit
Insert, modify, delete, cancel
Program No., sequence No., address,
character retrieval
Yes
Decimal point programming
Yes
Display
800×480 pixels 7” LCD
Position screen, program edit
Tool compensation setting, alarm display
Hand wheel test, diagnosis screen
Parameter setting, graphic simulation
Yes
M, S, T function
Auxiliary function
M code
Spindle function
S0-S15 (shift control)
S15-S99999 (analog)
Tool function
T code
Compensation
Mold offset compensation function
Length of 30 sets of tools, radius
compensation

Adtech ADTECH4 CNC Series Specifications

General

Brand	Adtech
Model	ADTECH4 CNC Series
Category	Control Systems
Language	English
