ADTECH4 SeriesCNC Maintenance Manual
9.11 Current mode instruction info
Display the G code mode info of current system;
In [Monitor] interface, you can check the running code info of current system:
Motion instruction: G00, G01
Select plane: G17, G18, G19
Coordinate logic: G90, G91
Workpiece coordinate system: G54, G59, G591…G599
Radius compensation: G40, G41, G42
Length compensation: G43, G44, G49
Compound instruction retracting plane: G98, G99
Principal axis rotation: S
Tool No.: T
