ADTECH4 SeriesCNC Maintenance Manual
Default input port configuration of 46M series (milling machine)
Wire No.
Port Definition
Function
1
IN0
X axis zero point
2
IN1
Y axis zero point
3
IN2
Z axis zero point
4
IN3
A axis zero point
5
IN4
Backup input
6
IN5
Backup input
7
IN6
Backup input
8
IN7
Backup input
9
IN8
Backup input
10
IN9
Backup input
11
IN10
Backup input
12
IN11
Backup input
13
IN12
Backup input
14
IN13
Backup input
15
IN14
Backup input
16
IN15
Backup input
17
IN16(XLMT-)
X axis negative limit (backup IN32)
18
IN17(XLMT+)
X axis positive limit (backup IN33)
19
IN18(YLMT-)
Y axis negative limit (backup IN34)
20
IN19(YLMT+)
Y axis positive limit (backup IN35)
21
IN20(ZLMT-)
Z axis negative limit (backup IN36)
22
IN21(ZLMT+)
Z axis positive limit (backup IN37)
23
IN22(ALMT-)
A axis negative limit (backup IN38)
24
IN23(ALMT+)
A axis positive limit (backup IN39)
25
INCOM
Input common end INCOM (24V+, 12V+) connects to
internal or external power supply
