ADTECH4 SeriesCNC Maintenance Manual
Default output port configuration of L series (lathe)
Wire No.
Port Definition
Function
1
OUT0
Principal axis positive rotation (M03)
2
OUT1
Principal axis reverse rotation (M04)
3
OUT2
Tool regulator positive rotation output (M18, M19)
4
OUT3
Tool regulator reverse rotation & locking output
(M20, M21)
5
OUT4
Cooling (M08, M09)
6
OUT5
Lubrication (M32, M33)
7
OUT6
backup output(M12, M13)
8
OUT7
backup output(M14, M15)
9
OUT8
Chuck locking (M10)
10
OUT9
Chuck loosening (M11)
11
OUT10
backup output(M22, M23)
12
OUT11
backup output(M24, M25)
13
OUT12
backup output(M26, M27)
14
OUT13
backup output(M128, M129)
15
OUT14
backup output(M130, M131)
16
OUT15
backup output(M34, M35)
17
OUT16
backup output(M36, M37)
18
OUT17
backup output(M38, M39)
19
OUT18
backup output(M52, M53)
20
OUT19
backup output(M54, M55)
21
OUT20
backup output(M56, M57)
22
OUT21
backup output(M46, M47)
23
OUT22
backup output(M48, M49)
24
OUT23
backup output(M50, M51)
25
OUTGND12V-, 24V- common power supply of
external output
12.2.4. Handheld box interface
