ADTECH4 SeriesCNC Maintenance Manual
(3) Reset machine tool position
Press the mode switch key [Home] to select home operation;
In [Absolute Position] and [Coordinate System] screen, press [X], [Y], [Z], [A]
respectively to show the value of corresponding axis position, and then press the [Cancel]
key to reset the machine tool position of current axis, i.e. current point is used as machine
tool origin. After this operation, the system considers it as a home action. Therefore,
when the program is running, the alarm of not home won’t occur. If you press by mistake,
it will switch the screen and cancel selection automatically.
(4) Reset relative position manually
Press the mode switch key [Manual] to select manual operation;
In [Relative Position] and [Coordinate System] screen, press [X], [Y], [Z], [A]
respectively to show the value of corresponding axis, and then press the [Cancel] key to
reset the relative position of current axis.
Note
The tool also can return to reference point according to program instruction, i.e. returning to reference point
automatically.
Caution:
Generally, the system will perform home operation after connecting the power supply. If the power fails while
the machine tool is moving, the system also will return to reference point when the power supply is connected
again. First return the z-axis to avoid collision of the tool and workpiece, which will result in damage to the
tool, workpiece and fixture.
4.2
Continuous Feeding Manually
Press the keys on the operation panel or hand wheel to move the tool along every axis.
The operation follows:
