ADTECH4 SeriesCNC Maintenance Manual
Default output port configuration of M series milling machine CNC4640(XS6), CNC4960(XS8)
Wire No.
Port
Definiti
on
Function
1
OUT0
Principal axis positive rotation (M03)(operation panel
M203)
2
OUT1
Principal axis reverse rotation (M04)(operation panel M204)
3
OUT2
(M10, M11) (FCNC4M panel chuckM10, M11)
4
OUT3
(M12, M13) (operation panel lighting M12, M13)
5
OUT4
Cooling (M08, M09)(operation panel cooling M208, M209)
6
OUT5
Lubrication (M32, M33)(operation panel lubrication M212,
M213)
7
OUT6
(M14, M15) (operation panel elastic tool M14, M15)
8
OUT7
(M16, M17) (operation panel cutter or manual tool magazine
M16, M17)
9
OUT8
(M18, M19) (operation panel tool magazine +M18, M19)
10
OUT9
(M20, M21) (operation panel tool magazine -M20, M21)
11
OUT10
(M22, M23) (operation panel chamber blowing M22, M23)
12
OUT11
(M24, M25) (operation panel chip removal M24, M25)
13
OUT12
(M26, M27) (FCNC6D panel chip removal 2 M26, M27)
14
OUT13
(M128, M129) (FCNC6D panel cooling 2 M128, M129)
15
OUT14
(M130, M131) (FCNC6D panel loose material M130,
M131)
16
OUT15
(M34, M35) (FCNC6D panel discharge M34, M35)
17
OUT16
(M36, M37) (FCNC6D panel feeding M36, M37)
18
OUT17
(M38, M39) (FCNC6D panel principal axis positioning
M38, M39)
19
OUT18
(M40, M41) (operation panel F0 M40, M41)
20
OUT19
(M42, M43) (operation panel F1 M42, M43)
21
OUT20
(M44, M45) (operation panel F2 M44, M45)
22
OUT21
(M46, M47) (operation panel F3 M46, M47)
23
OUT22
(M48, M49) (operation panel F4 M48, M49)
