ADTECH4 SeriesCNC Maintenance Manual
11.7 Port configuration (P6.)
001
Tool setting gauge detection port number
…
…
048
X Y Z A B C enable output port number
Range
:
0~23
Unit
:
Terminal No.
Authority
:
Super admin
Default
:
The port table in the manual
Effective time
:
Instant
Note
:
Set the input or output port number assigned to configure system
functions;
To shield this function, you can type 8888 and press Insert. This
operation is in background, and displays “=========” if the operation
is successful.
049
Input detection effective voltage level 00 ~ 31
050
Input detection effective voltage level 32 ~ 63
051
Input detection effective voltage level 64 ~ 95
Range
:
0x00000000~0xFFFFFFFF
Unit
:
Authority
:
Super admin
Default
:
0
Effective time
:
Instant
Note
:
Used to configure IO detection effective voltage level, 0: Low 1: High.
Use binary system to configure in positions.
For example: P6.050:10, is 00000000 00000000 00000000 00001010 in
binary system;
which indicates that among input ports IN32 ~ IN63, IN33 IN35 IO
detection effective voltage level is high, while other IO detection
effective voltage levels are low.
052
IO Conf in RESET 00~31
