ADTECH4 SeriesCNC Maintenance Manual
053
IO Conf in RESET 32~63
054
IO Conf in RESET 64~95
Range
:
0x00000000~0xFFFFFFFF
Unit
:
Authority
:
Super admin
Default
:
0
Effective time
:
Instant
Note
:
Used to configure the IO that the system needs to reset when there is
alarm. 0: No; 1: Yes
Used to configure the IO signal that the system needs to reset when there
is alarm.
For example: P6.53:10, is 00000000 00000000 00000000 00001010 in
binary system;
which indicates that among OUT32 ~ OUT63, OUT33 is reset when the
system resets or alarms, OUT35 turns off, while other output ports are
not reset.
055
LED Conf in RESET 00~31
056
LED Conf in RESET 32~63
057
LED Conf in RESET 64~95
Range
:
0x00000000~0xFFFFFFFF
Unit
:
Authority
:
Super admin
Default
:
0
Effective time
:
Instant
Note
:
Used to configure the LED that the system needs to reset when there is
alarm. 0: No; 1: Yes
LED
For example: P6.56:10, is 00000000 00000000 00000000 00001010 in
binary system;
which indicates that among LED32 ~ LED63, LED33 is reset when the
system resets or alarms, LED35 turns off, while other LEDs are not reset.
