ADTECH4 SeriesCNC Maintenance Manual
 If there is no question, press [EOB] again to return the result to specified coordinate
system.
(2) Square centered
 Select the edit mode;
 Press [Coordinates], [Coordinates Parameter] to enter the auxiliary parameters setting
interface of the coordinate system;
 Move the cursor to desired position, enter new parameters and press [EOB];
 Select hand wheel or manual mode;
 Press [Coordinates] to enter coordinate system setting interface;
 Press the left/right arrow to move the cursor to select coordinate system;
 Press [Centered Measurement] to enter centered interface;
 Move the tool to make its side blade touch side A surface of the workpiece, and press
[EOB] to record boundary point 1;
 Move the tool to make its side blade touch side B surface of the workpiece, and press
[EOB] to record boundary point 2;
 Record boundary point 3.4 in the same method;
 Press [EOB] after recording all boundary points to calculate the coordinates of center
point;
 If there is no question, press [EOB] again to return the result to specified coordinate
system.
(3) Plane circle (XY plane) centered
Circle centered has two modes, which are three points and two points with specified radius; If the user
only types two coordinates in the option of workpiece boundary point and specifies one value for R, the system
will determine the circle center with two points and radius automatically; if the user types coordinates of three
