ADTECH4 SeriesCNC Maintenance Manual
Default input port configuration of 46L series XS5 (lathe)
WireNo.
Port Definition
Function
1
IN0
X axis zero point
2
IN1
Backup input
3
IN2
Z axis zero point
4
IN3
Backup input
5
IN4
Tool #1 in place test
6
IN5
Tool #2 in place test
7
IN6
Tool #3 in place test
8
IN7
Tool #4 in place test
9
IN8
Tool #5 in place test
10
IN9
Tool #6 in place test
11
IN10
Tool #7 in place test
12
IN11
Tool #8 in place test
13
IN12
Chuck pedal input
14
IN13
Backup input
15
IN14
Backup input
16
IN15
Backup input
17
IN16(XLMT-)
X axis negative limit (backup IN32)
18
IN17(XLMT+)
X axis positive limit (backup IN33)
19
IN18
20
IN19
21
IN20(ZLMT-)
Z axis negative limit (backup IN36)
22
IN21(ZLMT+)
Z axis positive limit (backup IN37)
23
IN22
24
IN23
25
INCOM
Input common end INCOM (24V+, 12V+) connects
to internal or external power supply
