ADTECH4 SeriesCNC Maintenance Manual
8
5V+
Internally provided +5V power
supply
9
IN56
Select X axis
10
IN57
Select Y axis
11
IN58
Select Z axis
12
IN59
Select A axis
13
IN62
Emergency stop
14
HB
Hand encoder phase B input signal
15
5V-
Internally provided -5V power
supply
12.2.5. Analog output interface (46 series XS8)
Analog output interface wiring diagram:
The wiring is also suitable for XS8 interface of 46 series controller;
