ADTECH4 SeriesCNC Maintenance Manual
J3
EVCC5V
Spindle encoder power 5V terminal
J3
EGND
Spindle encoder power 0V terminal
J3
Spindle
Pulse
PU+
Servo spindle position control PU+
J3
PU-
Servo spindle position control PU-
J3
DR+
Servo spindle position control DR+
J3
DR-
Servo spindle position control DR-
J3
PWM1
PWM1
J3
DAGND
Analog grounding
J3
DOUT1
0-10V first analog output
J3
DOUT2
0-10V second analog output
J3
Control
Port
IAXIS_IN1
Spindle alarm signal 1 input port
J3
+24V
Control signal common terminal +24V
J3
IAXIS_IN2
Spindle alarm signal 2 input port
J3
GND
Control signal common terminal GND
J3
CW
Spindle forward signal
J3
CCW
Spindle reverse signal
J3
S1
Spindle speed 1
J3
S2
Spindle speed 2
J3
S3
Spindle speed 3
J3
S4
Spindle speed 4
12.3.7. ET102A splitter wiring diagram
