ADTECH4 SeriesCNC Maintenance Manual
24
OUT23
(M50, M51) (FCNC6D panel F5 M50, M51)
25
OUTGND12V-, 24V- common power supply of external
output
Default output port configuration of M series milling machine CNC4960(XS15)
Wire No.
Port Definition
Function
1
OUT24
(FCNC6D panel F6 M52, M53)
2
OUT25
(FCNC6D panel F7 M54, M55)
3
OUT26
(FCNC6D panel F8 M56, M57)
4
OUT27
(FCNC6D panel F9 M58, M59)
5
OUT28
(FCNC6D panel F10 M60, M61)
6
OUT29
(FCNC6D panel F11 M62, M63)
7
OUT30
(FCNC6D panel F12 M64, M65)
8
OUT31
(FCNC6D panel F13 M66, M67)
9
OUT32
(backup output M68, M69)
10
OUT33
(backup output M70, M71)
11
OUT34
(backup output M72, M73)
12
OUT35
(backup output M74, M75)
13
OUT36
(backup output M76, M77)
14
OUT37
(backup output M78, M79)
15
OUT38
(backup output M80, M81)
16
OUT39
(backup output M82, M83)
17
OUT40
(backup output M84, M85)
18
OUT41
(backup output M86, M87)
19
OUT42
(backup output M90, M91)
20
OUT43
(backup output M92, M93)
21
OUT44
(backup output M94, M95)
22
OUT45
(backup output M96, M97)
23
OUT46
(backup output M198, M199)
24
OUT47
(backup output M100, M101)
