Adtech ADTECH4 CNC Series User Manual

ADTECH4 SeriesCNC Maintenance Manual
J2
GND
24V power output GND terminal
J2
X, Y
Axis Limit
X+
X axis positive limit
J2
X-
X axis negative limit
J2
Y+
Y axis positive limit
J2
Y-
Y axis negative limit
J2
POWER
+24V
24V power output terminal
J2
GND
24V power output GND terminal
J2
Z, A
Axis Limit
Z+
Z axis positive limit
J2
Z-
Z axis negative limit
J2
A+
A axis positive limit
J2
A-
A axis negative limit
J2
POWER
+24V
24V power output terminal
J2
GND
24V power output GND terminal
J2
B, C
Axis Limit
B+
B axis positive limit
J2
B-
B axis negative limit
J2
C+
C axis positive limit
J2
C-
C axis negative limit
J2
POWER
+24V
24V power output terminal
J2
GND
24V power output GND terminal
J2
X, Y, Z, Z
Origin
Switch
X
X axis origin
J2
Y
Y axis origin
J2
Z
Z axis origin
J2
A
A axis origin
J2
POWER
+24V
24V power output terminal
J2
GND
24V power output GND terminal
J2
B, COrigin
Switch
B
B axis origin
J2
C
C axis origin
J2
Press
IN14
Air pressure detection
J2
IN15
Vacuum detection
Termi
nal
Area
Port Name
Function

Adtech ADTECH4 CNC Series Specifications

General

Brand	Adtech
Model	ADTECH4 CNC Series
Category	Control Systems
Language	English
