Chapter 4 Maintenance Procedures112
USG-CUS-059 Rev05MassARRAY® Nanodispenser RS1000 v2.1 User Guide
For Research Use Only. Not for use in diagnostic procedures.
a. Orient the plate so that well A1 is located at the lower left corner of the plate holder
(Figure 4.34).
b. Lower the right edge of the plate to the deck, making sure that the top edge seats
against the alignment post at the top of the plate position.
The spring-loaded positioner will engage.
NOTE
See page 118 for instructions on loading a 96-well microtiter plate.
4. Go to the Maintenance screen (tap the Back button on any screen and tap the
MAINTENANCE button on the Main Menu).
5. Tap CONDITION WEEKLY on the Maintenance screen.
Figure 4.34 Placing a Microtiter Plate on the Nanodispenser RS1000 Deck
Figure 4.35 Select the Type of Microtiter Plate for Pin Conditioning
Spring-loaded
positioner
