Appendix A Changing the Pin Format 127
USG-CUS-059 Rev05MassARRAY® Nanodispenser RS1000 v2.1 User Guide
For Research Use Only. Not for use in diagnostic procedures.
10. Tap OK on the screen.
The next instructions appear (Figure A.18).
Figure A.17 Pins Extended for 6-pin Format
Figure A.18 Instructions for Next Steps
ABCD
1
2
3
4
5
6
ABCD
1
2
3
4
5
6
Base end of
pin
Extended pin
Retracted pin
Pin tip
Do not touch
= Pin extended for use
= Retracted pin not in use
6-pin format 1-pin format
