Figure 3.3 shows how the plate wells are mapped to the SpectroCHIP Array pads. The
diagrams represent a single plate and SpectroCHIP Array. The same mapping scheme is
used for each plate and SpectroCHIP Array in the 384 Plate to 384 SpectroCHIP Array
method. That is, MTP 1 is mapped to SpectroCHIP Array 1 and MTP 2 is mapped to
SpectroCHIP Array 2 using the mapping scheme shown in the diagrams.
Figure 3.2 384 MTP to 384 SpectroCHIP Array Mapping
MTP 1 MTP 2
SCOUT plate
384 SpectroCHIP
Arrays
384-well microtiter
plates
