1–2 SelectSet Avantra Series Control Panel and Operating Guide
Specifications and Features
The SelectSet Avantra 20 and SelectSet Avantra 25 are internal drum
laser imagesetters designed to provide high standards of image quality
and versatility. The following table lists their basic specifications.
Avantra 25E Avantra 25S
Maximum 17.7” x 25” 17.7" x 25"
Image Size 449 x 635 mm 449 x 635 mm
Resolutions 1200, 1800 1200, 1800,
2400 dpi 2400, 3600 dpi
Imaging Speed 417 sq. in./min. 625 sq. in./min.
@ 1200 dpi @ 1200 dpi
Avantra 20 Avantra 25
Maximum 13.7" x 20" 17.7" x 25"
Image Size 347 x 508 mm 449 x 635 mm
Resolutions 1200, 1800, 1200, 1800,
2400, 3600 dpi 2400, 3600 dpi
Imaging Speed 334 sq. in./min. 417 sq. in./min.
@ 1200 dpi @ 1200 dpi
