Using the Imagesetter Control Panel 2–35
Monitoring the Amount of Media
in the Take-up Cassette
n Specify the Take-up Alarm amount on the Feed Amounts screen
under the Pause screen.
n When the media fed into the take-up cassette exceeds this
amount, an alarm icon appears.
n The alarm blinks and the imagesetter goes into Pause Pending
mode; it goes into Pause mode when the current job is finished.
n When the Pause screen appears, feed and cut the media, remove
the full take-up cassette, and put an empty cassette in its place.
n To override the alarm, press Run. The imagesetter goes to the Run
screen and begins the next job; it goes into Pause Pending mode
again and then into Pause mode at the end of this job.
n You also can increase the Take-up Alarm amount. When the
imagesetter is in the Pause screen, press Feed Amounts, change
the alarm amount and continue imaging.
CAUTION: The maximum limit for the take-up cassette is 100
feet (30.4 m) with 4 mil media. Exceeding this limit can scratch
the media or jam the cassette.
Figure 2.26 Take-up alarm icon.
Appears in both the Run and Pause screens.
A
B
F
#1
PL
#2
