Using the Imagesetter Control Panel 2–23
Loading Media from a Supply Cassette
When you press Load, the imagesetter advances media from a supply
cassette into the drum.
Feeding and Cutting Media
Press Feed and Cut to advance media out of the drum.
The Output Mode that you specify in the Configuration screen affects
the Feed and Cut function. Your choices for Output Mode are Take-up
Cassette or On-line Processor.
When you use the take-up cassette mode:
n The imagesetter feeds imaged media past the cutter.
n Some unexposed media is advanced. The length of the unexposed
media is the Feed and Cut Amount, specified in the Feed Amounts
screen.
n The cutter cuts the media.
To Feed and Cut:
Press once and the icon
flashes.
Press again to complete
the feed and cut or...
...press Abort to cancel.
To Load a Supply:
A
Press once and the icon
flashes.
Press again to complete
loading or...
...press Abort to cancel.
A
