Agilent Technologies 1200 series - Page 185

Agilent 1200 Series Autosampler Reference Manual 185
Parts and Materials 5
Table 23 Preparative Injection-Valve Assembly for G2260A
Item Description Part Number
1MBB
*
-Injection-valve assembly, includes items1– 6
* MBB (Make Before Brake) is a trademark by Rheodyne
0101-1267
2 Isolation seal 0100-1852
3 - 4 Rotor seal (PEEK) + Stator face (PEEK) kit 0101-1268
5 Stator head 0100-2195
6 Stator screws 1535-4857
Figure 22 Injection-Valve Assembly
1
2
6
3
5
4
