230 Agilent 1200 Series Autosampler Reference Manual
7 Introduction to the Autosampler
Electrical Connections
WARNING
Never use cables other than the ones supplied by Agilent Technologies to ensure
proper functionality and compliance with safety or EMC regulations.
Figure 36 Autosampler (plus Thermostat) Electrical Connections
GPIB
RS232C
CAN-bus
Remote
Vial number output
Relay contacts
Connection
ALS - Thermostat
G1330B Thermostat
(optional)
