Agilent Technologies 1200 series - Power and Status Light Pipes

Agilent 1200 Series Autosampler Reference Manual 189
Parts and Materials 5
Power and Status Light Pipes
Table 27 Power and Status Light Pipes
Item Description Part Number
1 Power switch button 5041-8381
2 Light pipe — power switch 5041-8382
3 Power switch coupler 5041-8383
4 Light pipe — status lamp 5041-8384
Figure 26 Power and Status Light Pipes
1
2
3
4
