Agilent 1200 Series Autosampler Reference Manual 247
Theory of Operation 8
Interfaces
The Agilent 1200 Series modules provide the following interfaces:
• CAN connectors as interface to other Agilent 1200 Series modules,
• GPIB connector as interface to the Agilent ChemStation,
• RS-232C as interface to a computer,
• REMOTE connector as interface to other Agilent products,
• Analog Output connector(s) for signal output, and
• Interface slot for specific interfacing (external contacts, BCD, LAN and so
on).
For identification and location of the connectors Figure 6 on page 28.
Table 46 Agilent 1200 Series Interfaces
Interface Type Pumps Autosampler DA Detector
MW Detector
FL Detector
VW Detector
RI Detector
Thermostatted
Column
Compartment
Vacuum
Degasser
CAN Yes Yes Yes Yes Yes No
GPI B Yes Yes Ye s Yes Ye s N o
RS-232C Yes Yes Yes Yes Yes No
Re mo te Yes Yes Ye s Yes Yes Yes
Analog Yes No 2 × 1 × No Yes
*
Interface board Yes Yes Yes Yes No No
* The vacuum degasser will have a special connector for specific use. For details see description of main board.
WARNING
Never use cables other than the ones supplied by Agilent Technologies to ensure
proper functionality and compliance with safety or EMC regulations, see “External
Tray G1313-60004” on page 197.
