140 Agilent 1200 Series Autosampler Reference Manual
4 Repairing the Autosampler
Installing the Transport Assembly
1 Slide the transport assembly into the autosampler. 2 Ensure the slot on the top of the transport assembly
engages with the stud on the sampling unit.
On completion of this procedure:
• Ensure the transport assembly is seated firmly.
• Install the top cover and foam (page 134).
• Verify the transport assembly alignment (page 102).
Transport assembly
Sampling unit
