120 Agilent 1200 Series Autosampler Reference Manual
4 Repairing the Autosampler
Rotor Seal
Frequency Poor injection-volume reproducibility
Leaking injection valve
Tools required 1/4 inch wrench (supplied in accessory kit).
Hex key, 9/64 inch (supplied in accessory kit).
Parts required Rotor seal 0100-1853 (Vespel) for G1329A
Rotor seal 0100-1849 (Tefzel) for G1329A
Rotor seal 0101-1268 (PEEK) for G2260A
Preparations for this
procedure
Remove front cover.
Remove the leak tubing (if necessary).
CAUTION
The stator face is held in place by the stator head. When removing the stator head,
ensure the stator face does not fall out of the valve.
1 Remove all capillary fittings from the injection-valve ports. 2 Loosen each fixing bolt two turns at a time. Remove the
bolts from the head.
