Agilent Technologies 1200 series - Overview of Main Repair Procedures

Agilent 1200 Series Autosampler Reference Manual 109
Repairing the Autosampler 4
Overview of Main Repair Procedures
Figure 15 Main Assemblies
Needle
page 111
Rotor seal,
page 120
Metering seal,
page 124
Needle seat
page 114
Transport assembly,
page 139
ASM board,
page 157
Power supply,
page 169
