Analog Signal Output
The analog signal output can be distributed to a recording device. For details
refer to the description of the module’s main board.
GPIB Interface
The GPIB connector is used to connect the module with a computer. The
address and control switches next to the GPIB connector determine the
GPIB address of your module. The switches are preset to a default address and
recognized by the operating software from Agilent Technologies.
CAN Interface
The CAN is an intermodule communication interface. It is a 2-wire serial bus
system supporting high speed data communication and real-time requirement.
Remote Interface
The APG remote connector may be used in combination with other analytical
instruments from Agilent Technologies if you want to use features such as
common shut down, prepare, and so on.
Table 47 Default Addresses
Autosampler 28 Autosampler 28
Pump 22 RID 29
FLD 23
VWD 24 Autosampler (HP 1050) 18
Agilent 8453A 25 Pump (HP 1050) 16
DAD / MWD 26 VWD (HP 1050) 10
Column Compartment 27 DAD (HP 1050) 17
