178 Agilent 1200 Series Autosampler Reference Manual
5 Parts and Materials
Sampling Unit Assembly
Table 18 Autosampler Sampling Unit Assembly
Item Description Part Number
Sampling unit assembly for G1329A
Sampling unit assembly for G2260A
(The assy comes without injection valve and analytical head)
G1329-60008
G2260-60008
1 Sampling unit connector board (SUD) G1313-66503
2 Belt gear for metering unit and needle arm 1500-0697
3 Stepper motor for metering unit and needle arm 5062-8590
4 Loop capillary (100 µl) for G1329A / G2260A
Loop ext. capillary (900µl) for G1329A / G2260A
Union for (900 µl) loop extension capillary
01078-87302
G1313-87303
5022-2133
5 Analytical head assembly (100 µl) for G1329A
Preparative head assembly (900 µl) for G1329A (P<200Bar)
Preparative head assembly (900 µl) for G2260A (P<400Bar)
01078-60003
G1313-60007
G2260-60007
6 Inj. valve - Anal. head cap (160 mm 0.25 mm) for G1329A
Inj. valve - Prep. head cap (160 mm 0.50 mm) for G2260A
G1313-87301
G2258-87301
7 Injection valve assembly for G1329A
Injection valve assembly for G2260A
0101-0921
0101-1267
8 Leak sensor 5061-3356
9 Waste tube injection valve assy (120 mm) for G1329A / G2260A G1313-87300
10 Safety cover G1329-44105
11 Needle-seat assy (0.17 mm i.d 2.3 µl) for G1329A (STANDARD)
Needle-seat assy (0.12 mm i.d 1.2 µl) for G1329A
Needle-seat assy (0.50 mm i.d 20 µl) for G2260A
G1313-87101
G1313-87103
G2260-87101
12 Seat adapter G1313-43204
13 Safety flap G1313-44106
14 Flex board G1313-68715
