Agilent 1200 Series Autosampler Reference Manual 177
Parts and Materials 5
Table 17 Autosampler Main Assemblies
Item Description Part Number
1 Transport assembly for G1329A-2260A G1329-60009
2 Sampling unit assembly for G1329A
Sampling unit assembly for G2260A
(The assy comes without injection valve and analytical head)
G1329-60008
G2260-60008
3 Analytical head assembly (100 µl) for G1329A
Preparative head assembly (900 µl) for G1329A (P<200Bar)
Preparative head assembly (900 µl) for G2260A (P<400Bar)
01078-60003
G1313-60007
G2260-60007
4 Injection valve assembly for G1329A
Injection valve assembly for G2260A
0101-0921
0101-1267
5 Vial tray, thermostatted (see page 191) G1329-60011
6Gripper assembly G1313-60010
7 Illumination assembly G1367-60040
8 Autosampler Main Board (ASM) for G1329A-1389A-2260A G1329-69500
Standoff - GPIB connector (part not shown) 0380-0643
Standoff - remote connector (part not shown) 1251-7788
9 Ribbon cable, sample transport G1313-81601
10 Ribbon cable, sampling unit G1313-81602
Sampler - TCC cap (380 mm 0.1 mm id) for G1329A
Sampler - Column cap (600 mm, 0.5 mm id) for G2260A
01090-87306
G2260-87300
Power supply assembly (part not shown) 0950-2528
Screw M4, 8mm lg - power supply (part not shown) 0515-0910
BCD board (not shown) G1351-68701
Cable, autosampler to ALS thermostat (part not shown) G1330-81600
To Next Page
