Agilent 1200 Series Autosampler Reference Manual 55
Troubleshooting and Test Functions 3
Status Indicators
Two status indicators are located on the front of the autosampler. The lower
left indicates the power supply status, the upper right indicates the
autosampler status.
Power Supply Indicator
The power supply indicator is integrated into the main power switch. When
the indicator is illuminated (green) the power is ON.
Figure 13 Location of Status Indicators
Status indicator
Power supply indicator
