22 Agilent 1200 Series Autosampler Reference Manual
1 Installing the Autosampler
Figure 2 Recommended Stack Configuration for an Autosampler (Rear View)
Remote cable
CAN Bus cable to
Instant Pilot
CAN Bus cable
LAN to LC
ChemStation
Analog signal to
recorder
AC power
