30 Agilent 1200 Series Autosampler Reference Manual
1 Installing the Autosampler
8 Re-install the tray
9 Ensure the power switch on the front of the Autosampler is OFF and the
power cables are disconnected.
10 Connect the cable between the Autosampler and the Thermostat, see
Figure 9 on page 33.
11 Connect the power cables to the power connectors.
12 Connect the CAN cable to the other Agilent 1200 Series modules.
Figure 8 Air channel adapter
Air channel adapter
WARNING
Do not disconnect or reconnect the autosampler to ALS thermostat cable when the
power cords are connected to either of the two modules. This will damage the
electronics of the modules.
